Pressed Steel Tanks

The steel used in the manufacture of the tank plates, stays and cleats conform to the requirements of BS 4350:1972 grade 43A or ISO equivalent.

Flanges of Plates : The tank plates are pressed with a combined double flange at an angle of 45 degree and 90 degree to the face of the plate on four sides.

Stays and Cleats : The stays and cleats are made of steel angle bar and steel plate.

Bolts, Nuts and Washers: Hot Dipped Galvanised steel bolts, nuts and washers for internal and external.

Jointing Materials : Non toxic PVC foam to be used for all jointing between tank panel flange.

Tank Cover : Panel type tank cover supported by trusses and poles 600 x 600 square manhole supplied as standard for each compartment.

Water Level Indicator : Transparent tube with aluminium casing and height level making.

Description
